Ürün Detayları
Place of Origin: GuangDong, China
Marka adı: LINK-PP
Sertifika: ISO9001,SGS,UL,CE,REACH
Model Number: 7498111124
Ödeme ve Gönderim Koşulları
Minimum Order Quantity: 50/500/1000/25K
Fiyat: $0.3-$2.8
Packaging Details: Tray
Delivery Time: About 1-2 Days
Payment Terms: TT,NET30/60/90 Days
Supply Ability: 3000000/Month
Mount: |
Through Hole Reflow |
PoE: |
non-PoE |
Tab Direction: |
Tab Down |
Speed: |
1000BASE-T |
LED L / R Color: |
Yellow-Green |
EMI Tabs: |
With |
RoHS Compliant: |
Support |
Operating Temperature: |
-40 °C up to +85 °C |
Inductance: |
350 µH (min) |
Turns Ratio: |
1:1 |
Mount: |
Through Hole Reflow |
PoE: |
non-PoE |
Tab Direction: |
Tab Down |
Speed: |
1000BASE-T |
LED L / R Color: |
Yellow-Green |
EMI Tabs: |
With |
RoHS Compliant: |
Support |
Operating Temperature: |
-40 °C up to +85 °C |
Inductance: |
350 µH (min) |
Turns Ratio: |
1:1 |
The 7498111124 is a WE-RJ45LAN series Through Hole Reflow RJ45 Connector with integrated magnetics, suitable for 1000BASE-T Ethernet applications. This product complies with IEEE 802.3ab standards and is RoHS and REACH compliant.
| Specification | Details |
|---|---|
| Connector Type | THR RJ45 Magnetic Connector |
| Number of Ports | 1 |
| Part Number | 7498111124 |
| Speed | 10/100/1000Base-T |
| Tab | Down |
| PoE | Non |
| Improved CMRR | NO |
| Shielding | Shielded With EMI Fingers |
| Mounting Type |
Through-Hole Reflow |
| LED Indicators | yellow-green LEDs |
| Operating Temperature | -40 °C up to +85 °C |
| Compliance | IEEE 802.3, RoHS |
| Applications | EtherCAT or Profinet, as well as hubs, routers, switches, IP cameras, and IoT applications. |
