Ürün Detayları
Menşe yeri: Guangdong, Çin
Marka adı: LINK-PP
Sertifika: IEEE 802.3ae, RoHS, IEC 60825-1
Model numarası: AFCT-701SDZ
Ödeme ve Gönderim Koşulları
Min sipariş miktarı: 1 adet, 10 adet
Fiyat: $3.1-$5
Ambalaj bilgileri: makara
Teslim süresi: 2-3 gün
Ödeme koşulları: L/C, D/A, D/P, T/T, Western Union
Yetenek temini: 5kk/ay
Dalgaboyu: |
1310nm |
Veri hızı: |
10 gbps |
İletim Mesafesi: |
10km (10GBASE-LR) |
Güç Tüketimi: |
850mW |
Bağlayıcı: |
LC Dubleks |
Teşhis arayüzü: |
SFF-8472 DOM |
Lazer Tipi: |
DFB (Dağıtılmış Geri Bildirim) |
Alıcı Tipi: |
PIN (Fotodiyot) |
Dalgaboyu: |
1310nm |
Veri hızı: |
10 gbps |
İletim Mesafesi: |
10km (10GBASE-LR) |
Güç Tüketimi: |
850mW |
Bağlayıcı: |
LC Dubleks |
Teşhis arayüzü: |
SFF-8472 DOM |
Lazer Tipi: |
DFB (Dağıtılmış Geri Bildirim) |
Alıcı Tipi: |
PIN (Fotodiyot) |
The Avago AFCT-701SDZ is a high-performance 10Gb Ethernet SFP+ transceiver designed to meet the 10GBASE-LR standard. Utilizing 1310nm DFB laser and PIN detector technology, it delivers reliable long-range connectivity. Engineered for high-density applications, this transceiver adheres to enhanced SFP+ specifications developed by the SFF Committee. The AFCT-701SDZ supports low power consumption with 850mW typical dissipation and features a digital diagnostic interface for real-time monitoring and predictive failure identification, ensuring consistent system uptime and performance.
| Parameter | Minimum | Typical | Maximum | Units | Notes |
|---|---|---|---|---|---|
| Transmitter | |||||
| Laser OMA output power | -5.2 | - | - | dBm | 1 |
| Laser mean output power | -8.2 | 0.5 | - | dBm | 1 |
| Laser off power | - | - | -30 | dBm | 1 |
| Extinction ratio | 3.5 | - | - | dB | 1 |
| Transmitter and dispersion penalty (TDP) | - | - | 3.2 | dB | 1 |
| Center Wavelength | 1260 | - | 1355 | nm | 1 |
| Side Mode Suppression Ratio - SMSR | 30 | - | - | dB | 1 |
| RIN12OMA | - | - | -128 | dB/Hz | 1 |
| Optical Return Loss Tolerance | - | - | 12 | dB | 1 |
| Transmitter Output Eye Mask | - | - | - | - | 1, See Figure 4b |
| Receiver | |||||
| Stressed sensitivity (OMA) | - | - | -10.3 | dBm | 1 |
| Receive sensitivity (OMA) | - | - | -12.6 | dBm | 1 |
| Receive Power (Pave) Overload | - | - | 0.5 | dBm | 1 |
| Reflectance | - | - | -12 | dB | 1 |
| Center Wavelength | 1260 | - | 1355 | nm | 1 |
| RX_LOS (OMA) De-Assert | - | - | -17 | dBm | 3 |
| RX_LOS (OMA) Assert | - | - | -30 | dBm | 3 |
| RX_LOS (OMA) Hysteresis | 0.5 | - | - | dB | - |
| Vertical eye closure penalty | - | - | 2.2 | dB | 2 |
| Stressed eye jitter | - | - | 0.3 | UI p-p | 2 |
